Reliable Network Cabling with Enhanced EMI Protection
The FTP CAT5E Ethernet Cable is designed for stable and efficient network transmission in environments where electromagnetic interference (EMI) may affect signal quality. Featuring four twisted pairs protected by an overall aluminum foil shield, the cable provides improved noise resistance and reliable performance for modern structured cabling systems.
Supporting data transmission speeds up to 1 Gigabit Ethernet and frequencies up to 100MHz, FTP CAT5E cable is widely used in office networks, commercial buildings, smart building infrastructure, surveillance systems, and industrial applications.
Key Features
- Category 5e Shielded Twisted Pair (FTP)
- Supports 10/100/1000 Mbps Ethernet
- Bandwidth up to 100MHz
- Overall Foil Shield for EMI Protection
- 24AWG Solid Bare Copper Conductor
- Stable Signal Transmission up to 100 Meters
- Available in PVC or LSZH Jacket
- RoHS Compliant
Applications
Suitable for a wide range of networking environments, including:
- Office LAN Networks
- Smart Building Systems
- IP Surveillance (CCTV)
- VoIP Communication
- Wireless Access Points
- Industrial Control Networks
Technical Specifications
- Conductor: 24AWG Solid Bare Copper
- Shielding: Aluminum Foil (FTP)
- Impedance: 100 ± 15 Ω
- Bandwidth: 100MHz
- Data Rate: Up to 1Gbps
- Jacket: PVC / LSZH
- Standard Length: 305m (1000ft)
OEM & Customization
OEM and ODM services are available, including custom cable colors, jacket printing, private label packaging, and customized lengths to meet project requirements.
Our FTP CAT5E Cable offers a cost-effective solution for reliable network connectivity while providing additional protection against external interference, making it an ideal choice for commercial and enterprise cabling projects.
