Ultra High-Speed Shielded CAT8 Ethernet Patch Cable for 25G / 40G Networks
Our FTP CAT8 Patch Cord is engineered for ultra-high-speed data transmission and next-generation networking environments. With advanced shielding structure and high-frequency performance, CAT8 cables support extremely high bandwidth applications such as data centers, enterprise backbone networks, and high-performance computing systems.
Designed for superior signal integrity and minimal interference, our CAT8 patch cords deliver reliable performance for demanding 25G/40G Ethernet applications over short distances.
As a professional network cable manufacturer, we provide OEM and ODM services for wholesalers, distributors, system integrators, and private label brands worldwide.
Key Features
• Category: CAT8 FTP (Foiled Twisted Pair)
• Data Transmission Speed: Up to 25–40 Gbps
• Bandwidth: Up to 2000 MHz
• Shielding: Overall Aluminum Foil Shield (FTP)
• Connector: RJ45 Male to RJ45 Male
• Conductor Material: Bare Copper / High-Purity Copper Optional
• Cable Gauge: 22AWG / 23AWG or Customized
• Jacket Material: PVC / LSZH Optional
• Ultra-Low Crosstalk and EMI Resistance
• High-Frequency Stable Transmission
• Available in Various Lengths and Colors
Technical Specifications
Category: CAT8 FTP
Connector Type: RJ45 8P8C Male to Male
Shielding Type: Overall Foil Shield (FTP)
Conductor Material: Bare Copper / High-Purity Copper
Conductor Gauge: 22AWG / 23AWG or Customized
Bandwidth: Up to 2000 MHz
Data Rate: Up to 25–40 Gbps (Short Distance)
Jacket Material: PVC / LSZH
Cable Length: 0.5m, 1m, 2m, 3m, 5m, 10m or Customized
Color Options: Blue, Black, Grey, White, Yellow, Red, Green or Customized
Standards: ANSI/TIA-568.2-D, ISO/IEC 11801, IEC 61156
Applications
• Data Centers and High-Density Server Rooms
• 25G / 40G High-Speed Network Infrastructure
• Cloud Computing and Storage Systems
• Enterprise Backbone Networks
• High-Performance Computing (HPC)
• Smart Buildings and Advanced IoT Systems
• Telecommunications Core Networks
OEM & ODM Services
We provide full customization solutions, including:
• Custom cable lengths and colors
• Private label and logo printing
• Custom packaging design (retail or bulk)
• PVC or LSZH jacket options
• Barcode and SKU labeling
• Engineering support for special networking projects
Quality Assurance
All CAT8 FTP Patch Cords are manufactured under strict quality control and tested for high-frequency performance, shielding effectiveness, and transmission stability to ensure compliance with international standards.
